Fixed Chemical injectors have been developed to allow downstream injection of chemicals. Downstream refers to 'after the pump and unloader' where the injector creates a Venturi effect (vacuum through the chemical hose) when used in conjunction with a low-pressure nozzle. Our Italian made, High-draw commercial injectors allow up to a 20% draw rate.

You may size your chemical injector using the GPM chart below, but keep in mind that chemical draw will typically increase when using an injector with a smaller orifice. The tradeoff for using a smaller orifice is a reduction in PSI. Many “soft washers” use small orifice injectors to allow for stronger chemical percentages, as well as the ability to facilitate longer runs of hose.

• 1.6 orifice: 2.1 to 3.2gpm
• 1.8 orifice: 3.2 to 4.2gpm
• 2.1 orifice: 4.2 to 5.5gpm
• 2.3 orifice: 5.5 to 6.6gpm

This model is a Fixed version with Stainless Steel ball and seat.

3/8" Male NPT Inlet x 3/8" Male NPT Outlet

Max - 300° F

    WARNING

This product can expose you to chemicals, including Lead which is known to the state of California to cause cancer or birth defects or other reproductive harm, go to www.p65Warnings.ca.gov for more information.

The products we sell are not intended for use in potable water systems and are only for industrial non-drinking water applications.
